Teleco Automation DMC 0/1-10V Dimmer and Receiver TVDMCxxxBB10
|
|
Luminux is proud to present you the Intense 0/1-10V Dimmer Receiver
which allows the user to adjust the brightness to the desired level
to create scene settings and atmospheres.
Intense 0/1-10V Dimmer receiver is suitable for different kinds of 0/1-10V control devices i.e. ballast or transformers for fluorescent light, LED drivers for LED lamps and strips.
Thanks to the built-in radio module it can be wireless controlled
by remote transmitters. It is equipped with fade function at
switch-on and off of the light, with memory function of the last
level of lighting and with and push-buttons UP/DOWN/OFF for manual
regulation. It perfectly integrates with the products of the Intense
range and if controlled by a 7-channel transmitter it is possible
to pre-set 4 light scenes. |
|
|
 |
|
¡@ |
Suitable for 0/1-10V command devices: 0/1-10V ballast or transformer for fluorescent, 0/1-10V LED drivers for LED lamps and strips |
|
¡@ |
Built-in relay |
|
¡@ |
Indestructible. 100% protected against short circuits and overheating |
|
¡@ |
Easy and Flexible Installation - Directly connect 230V to the relay output or connect 0/1-10V signal only
|
|
¡@ |
Wireless - built-radio module to create scene settings with the transmitters |
|
¡@ |
Interchangeable frames in different colours (White / Black) and materials (Poly Glass, Stainless Steel or Glass),
available on request |
|
¡@ |
Programmable for minimum light level, fade function at switch ON and OFF, memeory last level of light |
|
¡@ |
Compatible with all series Teleco Automation Transmitters |
|
¡@ |
PUSH Button Input for 2 ways Dimming |
|
|
 |
¡@ |
|
 |
¡@ |
 |
|
Model No |
TVDMCxxxBB10 |
|
Input Power |
220-230VAC, 50/60Hz |
|
Maximum Load to the Relay |
230VAC 800W |
|
Dimming Signal |
0-10V and 1-10V |
|
Operating Temperature |
-20ºC + 50ºC |
|
Remote Controllable |
Yes |
|
Switch Controller Size |
L86 x W86 x H36(mm) |
 |
|
¡@ |
 |
|
|
¡@ |
 |
|
