Luminux SG140SQ Waterproof LED Light


Luminux is proud to present you the SG140SQ which is perfect for the path, lobby, garden and pool. This unique Italian one piece stainless steel housing design and tempered glass cover makes the product in highest IP68 protection rating. With three high power LED build-in design and produced up to 300 lumen by 3W only, it is now possible to reduce energy consumption and maintenance costs without compromising on light quality and ambience.

¡@ Superior Italian Design
¡@ 316 Stainless Steel Housing
¡@ Tempered Glass Light Cover
¡@ IP68 Protection Rating
¡@ Ultra-easy Installation
¡@ Build-in Three High Power LED (Cree, USA)
¡@ Super Long Life - 70% maintenance of lumen after 50000 hours
¡@ Super High Color Rendering (85CRI)
¡@ Wide selection of Color
¡@ Dimming Options: EcoSystem, DALI, 1-10V, TRIAC, DMX
¡@ RoHS Compliant
¡@ UV and IR Free



¡@
¡@ ¡@
¡@
Item LED Color Lens angle Finishing Power Supply mA Watt Lumen Connection
SG140
White
20º Stainless Steel Constant Current 350 3 300 Serial
¡@
Warm-White
60º ¡@ 12/24VDC ¡@ 3 300 Parallel
¡@
Red
¡@ ¡@ ¡@ ¡@ ¡@ ¡@ ¡@
¡@
Green
¡@ ¡@ ¡@ ¡@ ¡@ ¡@ ¡@
¡@
Blue
¡@ ¡@ ¡@ ¡@ ¡@ ¡@ ¡@
¡@
Amber
¡@ ¡@ ¡@ ¡@ ¡@ ¡@ ¡@
¡@
RGB (Cree, USA)
¡@ ¡@ Constant Current 350 3 R/G/B Serial
¡@ Indoor and outdoor spotlight / general Lighting ¡@ Garden
¡@ Indoor and Outdoor Path ¡@ Walls
¡@ Balcony Deck ¡@ Steps
¡@ Aisle ¡@ Pool
¡@ Corridor ¡@ ¡@
¡@

IP68

¡@
