Luminux is proud to present you the Morgan series of LED Tracklight which is perfect for the retail
shops, offices, window displays, and most of commercial and architectural lighting. This unique simple
design comes with the cutting edge LED technology and heat dissipation technology. It adopts high power LED
(Cree, USA) technology which can produce up to 480 lumen with 9W only. The highest color rendering option can be up to
84CRI. It is now possible to reduce energy consumption and maintenance costs without compromising on light quality and
ambience.
Input Voltage
12VDC / 24VDC
LED Quantity
3
x 3W
Power Consumption
9W
per unit
Maximum Units Per Track
4 unit
LED Classification
High Power Cree 3W (700mA)
Color Temperature
Natural White / Warm White
Life Span
50,000hrs
Operation Temperature
-20¢XC ~ +50¢XC
Standard Lens Angle
40¢X
Weight
240g (Exclude Driver & Track)
Dimming
Yes
(Optional Dimmer Required)
Exclusive LED Driver
Included
¡@
¡@
¡@
LED
Driver: Luminux VA-24040D006: Input 170 - 250VAC,
Output 24VDC
LED Driver: Luminux VA-12030M: Input 170 - 250VAC,
Output 12VDC
