Luminux Nexus Facet Multifunction LED Panel Light


Luminux is proud to present you the Nexus Facet Multifunction LED Panel Light which is perfect for the general office, retail shops, supermarkets, and most of commercial lighting. This ultra slim and elegant design comes with the cutting edge LED technology and heat dissipation technology. It adopts LED Edge Lite technology to minimize the glare effect. The soft and uniform illuminance creates a high quality visual environment for the users. It is now possible to reduce energy consumption and maintenance costs without compromising on light quality and ambience.

¡@ Ultra Slim and Elegant Design
¡@ Multifunction: Recess Mount, Surface Mount, Suspended Hanging
¡@ AL6063-T5 Aluminum Edge Cooling System
¡@ Super Light Transmission PMMA Light Guide
¡@ Ultra Easy Installation
¡@ Power Option: 15W, 22W, 40W, 54W
¡@ Dimming Options: EcoSystem, DALI, 0/1-10V, TRIAC
¡@ Super Long Life - 70% maintenance of lumen after 50000 hours
¡@ Super High Color Rendering (80CRI)
¡@ Soft Beam Angle: 120º
¡@ Power Factor >0.9
¡@ RoHS Compliant
¡@ UV and IR Free



¡@



¡@
¡@
Item LED Color Lens angle Finishing Power Supply mA Watt Lumen Note
Nexus
3000K
120º Aluminum Frame 220VAC 15 1275
¡@
4000K
¡@ 22 1870
¡@
5000K
¡@ 40 3400
¡@ ¡@ 54 4590
¡@ ¡@
¡@ ¡@ ¡@ ¡@ ¡@ ¡@ ¡@
¡@ Retail Shops ¡@ Supermarket
¡@ General office Lighting ¡@ Commercial Lighting
¡@ Showrooms ¡@ Schools
¡@



IP20

¡@
